The John Deere X580 is a sturdy and versatile lawn and garden tractor from the X500 Select Series, designed for both residential and semi-professional use.

It offers strong performance, comfort, and durability for mowing, landscaping, and various outdoor tasks.

Below are some detailed parameters about the John Deere X580 Multi-Terrain tractor.

John Deere X580 Engine and Specifications

  • Engine Model: Kawasaki FS730V V-twin gasoline engine

  • Power: 24 HP (17.9 kW) iTorque™ Power System

  • Displacement: 44.3 cubic inches (726 cc)

  • Cooling: Air-cooled overhead valve with full pressure lubrication

  • Fuel Tank: 4.4 US gallons (16.7 liters) capacity, rear-mounted with gauge on dash

  • Air Cleaner: Dual-stage air cleaner (dry element with foam pre-cleaner)

  • Battery: 12V, 500 CCA

  • Starting System: Electric with solenoid shift

  • Hours Meter: Included

Transmission and Drive

  • Type: K72 hydrostatic integrated transaxle

  • Control: Twin Touch™ pedals for forward and reverse speed control

  • Speed: Forward up to 7.2 mph (11.6 km/h), Reverse up to 5.2 mph (8.4 km/h)

  • Cruise Control: Yes, button on dash

  • Brakes: Internal wet disc brakes

  • Differential Lock: Standard

Mower Deck and Cutting

  • Deck Type: 54-inch Accel Deep™ stamped steel mower deck

  • Cutting Height: 13 positions from 1 to 4 inches (2.5 to 10.2 cm), 0.25 inch increments

  • Deck Drive: Electric PTO clutch with in-line belt system

  • Mulch Control: Compatible with optional MulchControl™ kit for one-touch mulching

  • Mower Wheels: Four with seven-position spring-loaded adjustment

  • Wash Port: Yes, for easy cleaning

Frame and Chassis

  • Frame: Welded heavy-duty steel with powder coat finish

  • Steering: Hydraulic power steering with 14-inch wheel (non-tilt)

  • Tires: Front 16×6.5-8 turf tires, Rear 24×12-12 HDAP

  • Dimensions: Length 79 in (201 cm), Width with mower 68.4 in (174 cm), Height 45 in (114.3 cm)

  • Weight: Approx 787 lbs (357 kg) without fuel and attachments

Other Features

  • Seat: High-back, cut-and-sewn with 21-inch back height, adjustable fore-aft, and tilt seat suspension

  • Storage: Under-seat compartment and covered toolbox

  • Lights: Two 27W headlights, reflectors; no backup or rear work lights

  • Safety: Meets ANSI and OPEI safety standards; Reverse Implement Option for safety

  • Warranty: 4 years or 500 hours bumper-to-bumper limited warranty

John Deere X580 Key Features

  • Powerful and reliable Kawasaki V-twin engine with smooth power delivery

  • Easy-to-use hydrostatic transmission with Twin Touch pedals and cruise control

  • Durable 54-inch mower deck with optional MulchControl for flexible lawn care

  • Hydraulic power steering for smooth and easy maneuvering

  • Comfortable operator station with adjustable seat and ergonomic controls

  • Heavy-duty construction for multi-terrain residential and commercial landscape use

  • Easy maintenance with tool-free oil drain and replaceable filters

John Deere X580 Price

  • The John Deere X580 lawn tractor is priced in the range of approximately $3,500 to $4,200 USD depending on dealer, region, and optional attachments.

  • Exact prices vary, and promotions or discounts may apply seasonally.

Common Problems

  • Some users report occasional issues with the hydrostatic transmission including pedal sensitivity or noise, which usually respond to maintenance or service.

  • Starter solenoid failures may occur but are generally infrequent.

  • Normal wear on belts and mower blades requires periodic replacement.

  • Battery replacement needed typically every few seasons depending on usage.

  • Good maintenance practices (regular oil changes, filter replacements) mitigate most problems.

Manual and Support

  • The operator’s manual for the John Deere X580 is available on John Deere’s official website or through dealers.

  • The manual covers setup, operation, maintenance, troubleshooting, and safety instructions.

  • Support and parts are readily available through authorized John Deere dealers and service centers.

Conclusion

The John Deere X580 is a well-rounded and dependable lawn tractor suitable for homeowners with larger properties or smaller commercial tasks.

Its competitive specs, robust engine, comfort features, and long warranty make it a popular choice in the lawn and garden tractor market.
