John Deere 4710

The John Deere 4710 is a highly efficient and reliable self-propelled sprayer that has become a staple in modern agricultural operations.

Designed with precision and performance in mind, this sprayer offers farmers and agricultural professionals a robust solution for crop protection and pest management.

Whether you’re a small-scale farmer or managing a large agricultural enterprise, the John Deere 4710 delivers consistent and effective spraying results, enhancing productivity and crop quality.

Table of Contents

Introduction to the John Deere 4710

The John Deere 4710 is a compact utility tractor produced from 2002 to 2004 at John Deere’s Augusta, Georgia facility.

It belongs to the 4000 Ten Series, designed for versatility and efficiency in agricultural tasks.

Engine and Power

Gross engine power is rated at 46.3 horsepower (34.5 kW).

The engine runs at 2600 RPM to deliver 540 PTO RPM.

PTO power ratings include 38.5 hp for hydrostatic PTO and 40 hp for gear PTO.

Transmission and Drive

Offers two transmission options: a 12-speed power shuttle and a hydrostatic transmission.

Equipped with four-wheel drive for enhanced traction.

Features a mechanical rear differential lock and planetary final drives.

Power steering and wet disc brakes provide ease of operation and safety.

Advanced Spraying Technology

The John Deere 4710 is equipped with state-of-the-art spraying technology that ensures uniform coverage and minimal drift.

Its stainless steel eductor system is designed to provide optimal fluid flow and atomization, resulting in even distribution of pesticides, herbicides, and fertilizers.

This system is not only durable but also resistant to corrosion, ensuring long-term performance even in harsh field conditions.

Hydraulics and PTO

Hydraulic system is open center type with a capacity of 9.7 gallons (36.7 liters) and a pump flow of 10.6 gpm (40.1 lpm).

Hydraulic pressure is rated at 2500 psi (172.4 bar).

Rear lift capacity is 2,500 lbs (1,134 kg), suitable for a variety of implements.

Independent rear PTO with a wet disc clutch, operating at 540 RPM.

Optional mid PTO available at 2100 RPM for additional attachments.

Whether you’re working in narrow rows or wide-open fields, the ability to customize the tread width ensures stability and maneuverability, reducing the risk of crop damage.

Dimensions and Weight

Wheelbase measures 71.5 inches (181 cm).

Overall length approximately 134.6 inches, width 61.8 inches, and height 91.3 inches.

Operating weight is about 3,448 lbs (1,564 kg), making it relatively lightweight for its class.

Tire sizes: front 6.00-16, rear 13.6-24.

Attachments and Utility

Compatible with a range of attachments including a 72-inch mid-mount mower deck, front-end loader, and backhoe.

The tractor’s versatility and power make it suitable for various agricultural tasks such as mowing, loader work, and light excavation.

On-Board Air System

An on-board air system with marker capabilities is included, which aids in precise boom positioning and overlap management.

This system ensures that there are no gaps or overlaps in the spray pattern, maximizing the efficiency of the application

Boom Configuration

The sprayer typically features a multi-section boom that can be adjusted to cover varying widths, depending on the field size and crop layout.

The boom sections are equipped with strainers to prevent clogging and ensure a steady flow of spray solution.

Guidance-Ready System

The John Deere 4710 comes with a guidance-ready system, which can be easily integrated with precision agriculture technologies.

This feature enables operators to follow pre-programmed paths, ensuring accurate and efficient spraying.

The Autotrac Boom return to height function further enhances this capability by automatically adjusting the boom height to maintain consistent spray coverage.

Robust Construction

Built to withstand the rigors of daily farm operations, the 4710 features a sturdy underframe with shields and strainers to protect critical components from debris and damage.

The full boom breakaway design adds an extra layer of safety, allowing the boom to detach in case of an obstacle, preventing costly repairs and downtime.

Additional Features

Platform equipped with a two-post folding ROPS (Rollover Protective Structure) for operator safety.

Electrical system includes a 12-volt battery with 690 CCA and a 40-amp alternator.

Fuel tank capacity is 12.5 gallons (47.3 liters).

Conclusion

The John Deere 4710 is a robust, versatile compact utility tractor with a reliable Yanmar engine, flexible transmission options, and strong hydraulic capabilities.

It is well-suited for small to medium-sized farms requiring a multi-purpose machine with good power, maneuverability, and attachment compatibility.

Whether you’re dealing with weeds, pests, or nutrient deficiencies, the John Deere 4710 provides a reliable and efficient solution to keep your crops healthy and productive.

Invest in the John Deere 4710 and experience the difference that precision agriculture can make in your farming operations.
